DE2-70 User Manual
61
DRAM0_CKE PIN_AA8 SDRAM 1 Clock Enable
DRAM0_CLK PIN_AD6 SDRAM 1 Clock
DRAM0_WE_N PIN_W9 SDRAM 1 Write Enable
DRAM0_CS_N PIN_Y10 SDRAM 1 Chip Select
DRAM1_A[0] PIN_T5 SDRAM 2 Address[0]
DRAM1_A[1] PIN_T6 SDRAM 2 Address[1]
DRAM1_A[2] PIN_U4 SDRAM 2 Address[2]
DRAM1_A[3] PIN_U6 SDRAM 2 Address[3]
DRAM1_A[4] PIN_U7 SDRAM 2 Address[4]
DRAM1_A[5] PIN_V7 SDRAM 2 Address[5]
DRAM1_A[6] PIN_V8 SDRAM 2 Address[6]
DRAM1_A[7] PIN_W4 SDRAM 2 Address[7]
DRAM1_A[8] PIN_W7 SDRAM 2 Address[8]
DRAM1_A[9] PIN_W8 SDRAM 2 Address[9]
DRAM1_A[10] PIN_T4 SDRAM 2 Address[10]
DRAM1_A[11] PIN_Y4 SDRAM 2 Address[11]
DRAM1_A[12] PIN_Y7 SDRAM 2 Address[12]
DRAM_D[16] PIN_U1 SDRAM 2 Data[0]
DRAM_D[17] PIN_U2 SDRAM 2 Data[1]
DRAM_D[18] PIN_U3 SDRAM 2 Data[2]
DRAM_D[19] PIN_V2 SDRAM 2 Data[3]
DRAM_D[20] PIN_V3 SDRAM 2 Data[4]
DRAM_D[21] PIN_W1 SDRAM 2 Data[5]
DRAM_D[22] PIN_W2 SDRAM 2 Data[6]
DRAM_D[23] PIN_W3 SDRAM 2 Data[7]
DRAM_D[24] PIN_Y1 SDRAM 2 Data[8]
DRAM_D[25] PIN_Y2 SDRAM 2 Data[9]
DRAM_D[26] PIN_Y3 SDRAM 2 Data[10]
DRAM_D[27] PIN_AA1 SDRAM 2 Data[11]
DRAM_D[28] PIN_AA2 SDRAM 2 Data[12]
DRAM_D[29] PIN_AA3 SDRAM 2 Data[13]
DRAM_D[30] PIN_AB1 SDRAM 2 Data[14]
DRAM_D[31] PIN_AB2 SDRAM 2 Data[15]
DRAM1_BA_0 PIN_T7 SDRAM 2 Bank Address[0]
DRAM1_BA_1 PIN_T8 SDRAM 2 Bank Address[1]
DRAM1_LDQM0 PIN_M10 SDRAM 2 Low-byte Data Mask
DRAM1_UDQM1 PIN_U8 SDRAM 2 High-byte Data Mask
