IO_B [4] PIN_H28 GPIO Connection 1 IO[4]
IO_B [5] PIN_L25 GPIO Connection 1 IO[5]
IO_B [6] PIN_K27 GPIO Connection 1 IO[6]
IO_B [7] PIN_L28 GPIO Connection 1 IO[7]
IO_B [8] PIN_K28 GPIO Connection 1 IO[8]
IO_B [9] PIN_L27 GPIO Connection 1 IO[9]
IO_B [10] PIN_K29 GPIO Connection 1 IO[10]
IO_B [11] PIN_M25 GPIO Connection 1 IO[11]
IO_B [12] PIN_K30 GPIO Connection 1 IO[12]
IO_B [13] PIN_M24 GPIO Connection 1 IO[13]
IO_B [14] PIN_L29 GPIO Connection 1 IO[14]
IO_B [15] PIN_L30 GPIO Connection 1 IO[15]
IO_B [16] PIN_P26 GPIO Connection 1 IO[16]
IO_B [17] PIN_P28 GPIO Connection 1 IO[17]
IO_B [18] PIN_P25 GPIO Connection 1 IO[18]
IO_B [19] PIN_P27 GPIO Connection 1 IO[19]
IO_B [20] PIN_M29 GPIO Connection 1 IO[20]
IO_B [21] PIN_R26 GPIO Connection 1 IO[21]
IO_B [22] PIN_M30 GPIO Connection 1 IO[22]
IO_B [23] PIN_R27 GPIO Connection 1 IO[23]
IO_B [24] PIN_P24 GPIO Connection 1 IO[24]
IO_B [25] PIN_N28 GPIO Connection 1 IO[25]
IO_B [26] PIN_P23 GPIO Connection 1 IO[26]
IO_B [27] PIN_N29 GPIO Connection 1 IO[27]
IO_B [28] PIN_R23 GPIO Connection 1 IO[28]
IO_B [29] PIN_P29 GPIO Connection 1 IO[29]
IO_B [30] PIN_R22 GPIO Connection 1 IO[30]
IO_B [31] PIN_P30 GPIO Connection 1 IO[31]
GPIO_CLKINN1 PIN_AH14 GPIO Connection 1 PLL In
GPIO_CLKINP1 PIN_AG15 GPIO Connection 1 PLL In
GPIO_CLKOUTN1 PIN_AF27 GPIO Connection 1 PLL Out
GPIO_CLKOUTP1 PIN_AF28 GPIO Connection 1 PLL Out
Table 5.8. Pin assignments for the expansion headers.
