DE2-70 User Manual
63
SRAM_DQ[8] PIN_AK17 SRAM Data[8]
SRAM_DQ[9] PIN_AJ17 SRAM Data[9]
SRAM_DQ[10] PIN_AH17 SRAM Data[10]
SRAM_DQ[11] PIN_AJ18 SRAM Data[11]
SRAM_DQ[12] PIN_AH18 SRAM Data[12]
SRAM_DQ[13] PIN_AK19 SRAM Data[13]
SRAM_DQ[14] PIN_AJ19 SRAM Data[14]
SRAM_DQ[15] PIN_AK23 SRAM Data[15]
SRAM_DQ[16] PIN_AJ20 SRAM Data[16]
SRAM_DQ[17] PIN_AK21 SRAM Data[17]
SRAM_DQ[18] PIN_AJ21 SRAM Data[18]
SRAM_DQ[19] PIN_AK22 SRAM Data[19]
SRAM_DQ[20] PIN_AJ22 SRAM Data[20]
SRAM_DQ[21] PIN_AH15 SRAM Data[21]
SRAM_DQ[22] PIN_AJ15 SRAM Data[22]
SRAM_DQ[23] PIN_AJ16 SRAM Data[23]
SRAM_DQ[24] PIN_AK14 SRAM Data[24]
SRAM_DQ[25] PIN_AJ14 SRAM Data[25]
SRAM_DQ[26] PIN_AJ13 SRAM Data[26]
SRAM_DQ[27] PIN_AH13 SRAM Data[27]
SRAM_DQ[28] PIN_AK12 SRAM Data[28]
SRAM_DQ[29] PIN_AK7 SRAM Data[29]
SRAM_DQ[30] PIN_AJ8 SRAM Data[30]
SRAM_DQ[31] PIN_AK8 SRAM Data[31]
SRAM_ADSC_N PIN_AG17 SRAM Controller Address Status
SRAM_ADSP_N PIN_AC18 SRAM Processor Address Status
SRAM_ADV_N PIN_AD16 SRAM Burst Address Advance
SRAM_BE_N0 PIN_AC21 SRAM Byte Write Enable[0]
SRAM_BE_N1 PIN_AC20 SRAM Byte Write Enable[1]
SRAM_BE_N2 PIN_AD20 SRAM Byte Write Enable[2]
SRAM_BE_N3 PIN_AH20 SRAM Byte Write Enable[3]
SRAM_CE1_N PIN_AH19 SRAM Chip Enable 1
SRAM_CE2 PIN_AG19 SRAM Chip Enable 2
SRAM_CE3_N PIN_AD22 SRAM Chip Enable 3
SRAM_CLK PIN_AD7 SRAM Clock
SRAM_DPA0 PIN_AK9 SRAM Parity Data[0]
SRAM_DPA1 PIN_AJ23 SRAM Parity Data[1]
