Sony AIRLINK HELIX 2140847 User Manual
Page 28
AirLink Helix User Guide
22
2140847
Figure 5-3: ACEmanager: Status - LAN/WiFi
VPN
The VPN section gives an overview of the VPN settings and indicates whether a
VPN connection has been made.
Figure 5-4: ACEmanager: Status - VPN
Command
Description
Ethernet Port 1
Address / status of the LAN port.
Ethernet Port 2
Address / status of the WAN / LAN port.
Security Encryption
type
Options are Open, WEP, or WPA. Shows the Wi-Fi encryption type.
WiFi Mode
The type of Wi-Fi network. If the Helix is configured exclusively as an 802.11g network, this
will show "Mixed" or "G-Only".
Connected Clients
Number of connected clients.
