GALAXY GG/GX SERIES BOILER
Location and identification of parts
Figure 14. GG Series—Hot Water Boiler
Figure 15. GX Series—Steam Boiler
Your gas boiler must be installed and serviced by a qualified service agency or
gas supplier. The lack of proper service can result in a dangerous condition.
4
Name and
Rating Plate
Lighting
Instructions
(inside front
panel)
Gas Valve
Burner
Access Door
Burners
Gas Manifold
Jacket Top
Relief Valve
Temperature
and Pressure
Gauge
Figure 16.
See lighting instructions on page 8.
Easy access front panel on stan-
dard extended jacket, is removed
by simply pressing hand against
panel and pushing up.
Jacket Top
Pop Safety Valve Pressure Gauge
Front
Panel
