Page 3
FEATURES
NOTES:
1. May be totally enclosed.
2. All clearance dimensions are
minimum.
3. All dimensions are in inches.
HEATER
ELEMENTS
CAST IRON
ASME HEAT
EXCHANGER
DUAL LIMIT AQUASTAT
CONTACTORS
FOR HEATER
ELEMENTS
SEQUENCER
ALTITUDE
PRESSURE
AND TEMPERATURE
GAUGE
30 PSI PRESSURE
RELIEF VALVE
CIRCUIT BREAKERS
TERMINAL
BLOCKS
CIRCULATOR
RELAY
DIMENSIONS
