2: Connecting the speakers
Before connecting the cords, be sure to
disconnect the AC power cord.
AFront speaker A (left)
BFront speaker A (right)
CCenter speaker
DSurround speaker (left) ESurround speaker (right)
FSurround back speaker (left)
b)
GSurround back speaker (right) b)
HSubwoofer c)
13 / 32"
(10 mm)
H G F
A D E B
A B
SPEAKERS FRONT
B terminals
a)
A Monaural audio cord (not supplied)
B Speaker cords (not supplied)
C
B
continued
