1 - 6

F: FILTER reset button

Use this button to reset the filter sign

. The air conditioner has a timer

for the filter and informs you when the filter needs cleaning.

G: CHECK button

This button is used only when servicing the air conditioner.

Do not use the CHECK button for normal operation.

H: UNIT button

When more than one indoor unit is connected, this button is used to
select a unit when adjusting the airflow direction.
If no unit is selected, the airflow direction of all units can be adjusted
concurrently using the FLAP button.

I: FLAP button

(

)

1. Use this button to set the airflow direction to a specific angle.

The airflow direction (

) is displayed on the remote control unit.

• In the cool mode and dry mode, when the flaps are set in a

downward position, condensation may form and drip around
the vent.

• Do not move the flap with your hands.

This function is available only for models X and T.

(

)

2. Use this button to make the airflow direction sweep up and down

automatically.

Press this button several times until the (

) symbol appears on

the display.

This function is available only for models X, T and K.

J: TIMER SET button

Use this button while the unit is operating to switch between timer
settings:

(OFF Timer)

:The air conditioner stops after the length of time set.

(OFF Cycle Timer)

:The air conditioner after the same set time every time.

(ON Timer)

:The air conditioner starts after the length of time set.

K: Time setting buttons

:Press this button to increase the time.

:Press this button to decrease the time.

L: SET button

Use this button to set the timer.

M: CL button

Use this button to clear the timer setting.

N: Temperature sensor of the

While the temperature sensor of the indoor unit usually detects ambient

remote controller

temperatures, it is also possible to detect temperatures around the
remote controller. For the detail of this functionality, consult your dealer.
(Do not use this functionality for group operation.)

O: VENTILATION button

Use this button when you installed a fan available in the market.
Pressing this button turns on and off the fan.
When turning off the air conditioner, the fan will be also turned off.

While the fan is operating,

will appear in the display. If

displayed when pressing the ventilation button, no fans are installed.

NOTE

Remote Control Unit (continued)

Operation mode

(COOL) or

(DRY)

(HEAT) or

(FAN)

(AUTO)

Cooling mode:
Heating mode:

Number of airflow direction settings

3
5

NOTE
