MX692 FEATURES AND CONTROLS
Microphone Status LED
Microphone is active when lit.
Programmable Touch-sensitive Switch
Touch to mute or activate microphone,
depending on logic settings.
Power/Battery Life Gauge
LED color indicates battery power status.
Power On/Off Switch
Protective Grille
Grille can be removed to access microphone
cartridge and DIP switches.
