CUSTOMIZING MICROPHONE SWITCH FUNCTIONALITY
Note: switch 4 of the MX692 DIP switch panel is not active
DESIRED SWITCH
FUNCTIONALITY
DESIRED LED FUNCTIONALITY DIP SWITCH SETTING
Push to mute, release to talk (as
shipped)
LED on when microphone is active
Push to talk release to mute LED on when microphone is active
Toggle: push on/push off LED on when microphone is active
O N GDH04
1 2 4 3
2C
O N GDH04
1 2 4 3
2C
O N GDH04
1 2 4 3
2C
O N GDH04
1 2 4 3
2C
Initially Muted Initially Active
