-61-
W1772/W1773 37" Drum Sander
PA
RT
S
Conveyor Parts List
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
185 XPN28M HEX�NUT�M20-2.5 233 X1772233 COLLAR
186 X1772186 TABLE 234 X1772234 COMPRESSION�SPRING
187 X1772187 TABLE�SUPPORT 235 X1772235 PULLEY
188 X1772188 TABLE�SUPPORT 236 X1772236 V-BELT�AX-25
189 XPB26M HEX�BOLT�M8-1.25�X�30 237 X1772237 PULLEY
190 XPLW01 LOCK�WASHER�5/16 238 X1772238 FEED�MOTOR�1/3HP�220V�1PH�(W1772)
191 X1772191 ROLLER�SUPPORT�BRACKET 238 X1773238 FEED�MOTOR�1/3HP�220/440V�3PH�(W1773)�
192 X1772192 ROLLER�SUPPORT�BRACKET 238-1 X1772238-1 MOTOR�FAN�COVER�(W1772)
193 XPB26M HEX�BOLT�M8-1.25�X�30 238-1 X1773338-1 MOTOR�FAN�COVER�(W1773)
194 XPLW01 LOCK�WASHER�5/16 238-2 X1772238-2 MOTOR�FAN�(W1772)
195 XPB141M HEX�BOLT�M12-1.75�X�80 238-2 X1773238-2 MOTOR�FAN�(W1773)
196 XPN09M HEX�NUT�M12-1.75 238-3 X1772238-3 CAPACITOR�COVER
197 X1772197 PRESSURE�ROLLER 238-4 X1772238-4 S.�CAP�75M�125V�35X�58
197-1 X1772197-1 PRESSURE�ROLLER�SHAFT 238-5 X1772238-5 CAPACITOR�COVER
198 X1772198 BEARING�6204-2RS 238-6 X1772238-6 R.�CAP�20M�300V�34X�51
199 X1772199 BRACKET 238-7 X1772238-7 FEED�MOTOR�JUNCTION�BOX�(W1772)
200 XPSS01M SET�SCREW�M6-1�X�10 238-7 X1773238-7 FEED�MOTOR�JUNCTION�BOX�(W1773)
201 X1772201 ROLLER�COVER 239 XPB07M HEX�BOLT�M8-1.25�X�25
202 X1772202 ROLLER�COVER 240 XPW07 FLAT�WASHER�5/16
203 XPSBS09M BUTTON�HD�CAP�SCR�M6-1�X�12 241 XPK112M KEY�5�X�5�X�55
204 XPW06 FLAT�WASHER�1/4 242 XPN03M HEX�NUT�M8-1.25
205 X1772205 CONVEYOR�BELT 243 X1772243 SHAFT
206 X1772206 ROLLER�SUPPORT�BRACKET 244 XPSS16M SET�SCREW�M8-1.25�X�10
207 X1772207 POINTER 245 X1772245 PULLEY
208 XPS09M PHLP�HD�SCR�M5-.8�X�10 246 XPSS01M SET�SCREW�M6-1�X�10
209 XPB26M HEX�BOLT�M8-1.25�X�30 247 X1772247 SPECIAL�PULLEY�BEARING
210 X1772210 ROLLER 248 X1772248 SHAFT
211 XPK34M KEY�5�X�5�X�20 249 XPB02M HEX�BOLT�M6-1�X�12
212 X1772212 BEARING�UCFL204 250 XPLW03M LOCK�WASHER�6MM
213 XPB32M HEX�BOLT�M10-1.5�X�25 251 X1772251 PULLEY
214 XPW02 FLAT�WASHER�3/8 252 XPR18M� EXT�RETAINING�RING�17MM
215 X1772215 ROLLER�SUPPORT�BRACKET 253 X1772253 BEARING�6003ZZ
216 XPB26M HEX�BOLT�M8-1.25�X�30 254 XPR12M EXT�RETAINING�RING�35MM
217 X1772217 GROMMET 255 X1772255 SPECIAL�NUT
219 X1772219 SPROCKET 256 XPN02M HEX�NUT�M10-1.5
220 XPSS16M SET�SCREW�M8-1.25�X�10 257 X1772257 KNURLED�COLLAR
221 X1772221 CHAIN�3/8 258 XPSS01M SET�SCREW�M6-1�X�10
222 X1772222 SPROCKET 259 X1772259 HANDWHEEL
223 XPK15M KEY�5�X�5�X�35 260 XPR45M INT�RETAINING�RING�10MM
224 XPSS16M SET�SCREW�M8-1.25�X�10 261 X1772261 SLEEVE
225 X1772225 GEAR�BOX 262 X1772262 BAR
226 XPW07 FLAT�WASHER�5/16 263 XPLN03M LOCK�NUT�M6-1
227 XPB126M HEX�BOLT�M8-1.25�X�40 264 X1772264 BAR
228 XPN03M HEX�NUT�M8-1.25 269 XPSBS09M BUTTON�HD�CAP�SCR�M6-1�X�12
229 X1772229 SHAFT 271 X1772271 COVER
230 XPSS16M SET�SCREW�M8-1.25�X�10 277 X1772277 INFEED�GUARD
231 XPK17M KEY�5�X�5�X�80 278 XPB02M HEX�BOLT�M6-1�X�12
232 XPR37M EXT�RETAINING�RING�32MM 279 XPW06 FLAT�WASHER�1/4
