-59-
W1772/W1773 37" Drum Sander
PA
RT
S
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
111-4 X1772111-4 CAPACITOR�COVER�(W1772) 168 X1772168 HINGE
111-5 X1772111-5 JUNCTION�BOX�(W1772) 169 XPSBS09M BUTTON�HD�CAP�SCR�M6-1�X�12
111-5 X1773111-5 JUNCTION�BOX�(W1773) 170 X1772170 KNOB�M6-1�X�12
111-6 X1772111-6 S.�CAP�300M�250V�45�X�97�(W1772) 171 X1772171 WHEEL�HANDLE
111-8 X1772111-8 CENTRIFUGAL�SWITCH�(W1772) 172 XPSS09 SET�SCREW�3/8-16�X�1/2
112 XPK109M KEY�7�X�7�X�35 173 X1772173 HANDWHEEL
113 XPB116M HEX�BOLT�M10-1.5�X�45 174 X1772174 HANDWHEEL�SLEEVE
114 XPW04M FLAT�WASHER�10MM 175 XPSS01M SET�SCREW�M6-1�X�10
115 XPN02M HEX�NUT�M10-1.5 176 XPN01M HEX�NUT�M6-1
116 X1772116 MAIN�MOTOR�PULLEY 177 X1772177 LIFT�SCREW
117 XPSS16M SET�SCREW�M8-1.25�X�10 178 XP51103 THRUST�BEARING�51103
117-1 XPSS09M SET�SCREW�M8-1.25�X�20 179 X1772179 CHAIN�3/8�PITCH
118 XPVB69 V-BELT�B-69�5L690 180 X1772180 SPROCKET
119 X1772119 BELT�COVER 180-1 X1772180-1 SPROCKET
120 XPSB168M CAP�SCREW�M6-1�X�90 180-2 XPK34M KEY�5�X�5�X�20
121 XPW06 FLAT�WASHER�1/4 180-3 XPSS11 SET�SCREW�1/4-20�X�1/4
122 X1772122 SIDE�PANEL 181 X1772181 SHAFT
123 XPB26M HEX�BOLT�M8-1.25�X�30 181-1 X1772181-1 BEARING�6000-2RS
124 X1772124 GAS�STRUT 181-2 XPR45M INT�RETAINING�RING�10MM
127 X1772127 FRONT�UPPER�FRAME�ANGLE 182 XPN02M HEX�NUT�M10-1.5
128 XPSBS09M BUTTON�HD�CAP�SCR�M6-1�X�12 183 XPW02 FLAT�WASHER�3/8
129 XPW06 FLAT�WASHER�1/4 184 X1772184 DRIVING�LIFT�SCREW
130 X1772130 MOUNTING�BRACKET 303 X1772303 STRAIN�RELIEF
132 X1772132 SHUT-OFF�BAR 304 X1772304 STRAIN�RELIEF
133 XPSBS09M BUTTON�HD�CAP�SCR�M6-1�X�12 305 X1772305 CABLE�CLAMP
135 X1772135 COMPRESSION�SPRING 306 X1772306 SWITCH�BOX
136 XPW06 FLAT�WASHER�1/4 307 XPW07 FLAT�WASHER�5/16
137 XPN01M HEX�NUT�M6-1 308 XPB07M HEX�BOLT�M8-1.25�X�25
138 XPN01M HEX�NUT�M6-1 309 X1772309 SUPPORT
139 X1772139 REAR�UPPER�FRAME�ANGLE 310 X1772310 SUPPORT�STRAP
140 X1772140 LEFT�SUPPORT�PLATE 311 XPB26M HEX�BOLT�M8-1.25�X�30
141 X1772141 RIGHT�SUPPORT�PLATE 312 XPN03M HEX�NUT�M8-1.25
142 XPSB26M CAP�SCREW�M6-1�X�12 313 X1772313 GEAR�BOX
143 XPW06 FLAT�WASHER�1/4 314 X1772314 SPROCKET�SHAFT
148 X1772148 METAL�PLATE 315 X1772315 SPROCKET
149 X1772149 PLATE 316 X1772316 GEAR
150 XPS01 PHLP�HD�SCR�10-24�X�1/2 317 XPSS01M SET�SCREW�M6-1�X�10
150-1 XPN07 HEX�NUT�10-24 318 X1772318 SPECIAL�WASHER
151 X1772151 KNOB�M8-1.25�X�55 319 X1772319 CONNECTING�SHAFT
155 X1772155 TOP�COVER 320 X1772320 BUSHING
156 X1772156 DUST�SCOOP 321 X1772321 WORM�GEAR
157 XPSB132M BUTTON�HD�CAP�SCR�M6-1�X�15 322 XPSS02M SET�SCREW�M6-1�X�6
158 XPW06 FLAT�WASHER�1/4 323 X1772323 OPEN�END�WRENCH
159 XPN35M ACORN�NUT�M6-1 324 XPAW04M HEX�WRENCH�4MM
160 X1772160 ADHESIVE�FOAM�STRIP 325 XPAW05M HEX�WRENCH�5MM
161 X1772161 ADHESIVE�FOAM�STRIP 340 X1772340 PHILLIPS�SCREWDRIVER
164 X1772164 HANDLE 356-1 X1772356-1 CONTROL�PANEL�ASSEMBLY�BOX
165 XPSB07 CAP�SCREW�5/16-18�X�3/4 348 XPS38M PHLP�HD�SCR�M4-.7�X�10
166 XPW07 FLAT�WASHER�5/16 556 X1772556 CONTROL�PANEL�PLATE
167 XPN02 HEX�NUT�5/16-18 566 X1772566 EMERGENCY�STOP�BAR�LIMIT�SWITCH
Frame Parts List
