Page 60

-58-

W1772/W1773 37" Drum Sander

PARTS

Frame Parts Breakdown

��

REF PART�#

DESCRIPTION

REF PART�#

DESCRIPTION

101

X1772101

MAIN�FRAME

110

XPN09M

HEX�NUT�M12-1.75

102

X1772102

LIFT�RING

111

X1772111

SANDING�DRUM�MOTOR�10HP�1PH�(W1772)

103

X1772103

SCALE

111

X1773111

SANDING�DRUM�MOTOR�15HP�3PH�(W1773)

105

X1772105

MOTOR�BASE

111-1 X1772111-1 MOTOR�COVER�(W1772)

106

XPB75M

HEX�BOLT�M12-1.75�X�35

111-1 X1773111-1 MOTOR�COVER�(W1773)

107

XPN09M

HEX�NUT�M12-1.75

111-2 X1772111-2 MOTOR�FAN�(W1772)

108

XPB143M

HEX�BOLT�M12-1.75�X�120

111-2 X1773111-2 MOTOR�FAN�(W1773)

109

XPW01

FLAT�WASHER�1/2

111-3 X1772111-3 R.�CAP.�50M�350V�45�X�85�(W1772)
