9
REFRIGERATOR COMPONENTS
Inside of front cover
1. Glow starter (with cover): This is for the fluorescent light. It is recommended that the glow starter
is also replaced when the fluorescent light is replaced. Refer to page 19.
2. Remote alarm terminal: This is used to connect the unit to an exterior alarm to notify users of any
malfunction. Refer to page 17.
3. Battery switch: Switch for battery used for power failure alarm. Always keep "ON". Turn the
switch "OFF" when the unit is in no use for a long period (more than 1 month).
Inside components of MBR-704G type
1. Shelf: Items to be stored in the chamber must be placed
on the shelves. The maximum storage weight for each shelf is
40 kg.
2. Bottom air duct: The duct keeps temperature inside the
chamber uniformly by making cooled air circulate. Put the
duct at the bottom of the chamber.
Do not put any articles under this duct. If this area is blocked,
temperature regulation will become unstable.
1 2
ON
OFF
3
1
2
