Getting to Know Your Camcorder
Front & Left View
1. Lens
2. Lens Cover
3. Remote Sensor
4. Hook for hand strap (see page 20)
5. TFT LCD monitor
6. Battery Pack (see page 22)
7. External MIC in (see page 62) 8. USB Jack (see page 73)
9. DV out (VP-D190MS only, see pages 71, 72)
DV in/out (VP-D190MSi)
10. Audio/Video (see page 67)
11. Earphone Jack
12. DC Jack (see page 21)
13. S-Video Jack
