ZT-2800 HYDRAULIC AXLE ASSEMBLY
1 HG71512 Kit, Fan & Pulley x
HG70489 Kit, Fan & Pulley x
2 HG51244 Nut, Hex Locking 1/2-20 x x
3 HG51523 Washer, Slotted x x
4 HG52576 Fan, 7” Dia. (10 Blade) x
HG51862 Fan, 7” Dia. (10 Blade) x
5 HG50302 Pulley, Cupped 4-1/2” Dia. x
HG52364 Pulley, Cupped 4-1/2” Dia. x
HG52366 Hub, Pulley x x
6 HG51190 Bolt, Hex Head 1/4-20 x 1-1/4” x x
7 HG52027 Clip, Retaining x x
8 HG52639 Handle, Brake x x
9 HG52640 Shaft, Brake x x
10 HG51804 O-Ring x x
11 HG9005110-5600 Plug, 9/16-18 x x
12 HG71572 Kit, Side Cover RH x x
HG71574 Kit, Side Cover LH x x
13 HG44121 Bearing, Ball .75 x 40 x 12 x x
14 HG52161 Spacer, .75 x 1.0 x .257 x x
15 HG52108 Gear, 54T x x
16 HG50132 Washer, .5 x 1.0 x .03 x x
17 HG52148 Gear, 43T x
HG52110 Gear, 45T x
18 HG52586 Gear, 11T Steel x x
19 HG51083 Jackshaft Pin x x
20 HG71413 Kit, Housing RH x x
HG71421 Kit, Housing LH x x
21 482800-03 Fitting x x
22 HG51329 Arm, Bypass x x
23 HG51627 Ring, Retaining .750 Internal x x
24 HG52136 Rod, Bypass x x
25 HG51628 Ring, Retaining .375 External x x
26 HG51626 Seal, Lip .375 x .75 x .25 x x
27 HG50329 Ring, Retaining 2.06 Internal x x
28 HG51161 Seal, Lip 17 x 40 x 7 x x
29 HG50951 Washer, 1.23 x 1.56 x .04 x x
30 HG2000022 Ring, Retaining Wire x x
31 HG50315 Bearing, Ball 17 x 40 x 12 Open x x
32 HG52155 Shaft, Input x x
33 HG71570 Shaft Kit, Axle x
HG71569 Shaft Kit, Axle x
34 HG50771 Bearing, Ball 1.0 x 52 x 15 Open x x
Ref. Part 48
No. No. Description 36 52
35 HG51630 Ring, Retaining .375 External x x
36 HG50772 Seal, Lip 25 x 52 x 10 TC Gray x x
37 HG50859 Ring, Retaining 2.06 Internal x x
38 HG71446 Kit, Hub x
HG71405 Kit, Hub x
HG71241 Hub, Puller (not shown) x x
39 HG50863 Nut, Hex Locking 3/4-16 x x
40 HG71595 Kit, RTN Assembly x x
41 HG51812 Bolt, 5/16-24 x 1” Patch x x
42 HG51950 Washer, .343 x 1.5 x .062 x x
43 HG71565 Kit, Center Section RH x x
HG71566 Kit, Center Section LH x x
44 HG51605 Spring x x
45 HG52682 Arm, Control x x
46 HG51945 Arm, Neutral RH x x
HG51946 Arm, Neutral LH x x
47 HG52527 Spacer, .320 x 1.005 x .179 x x
48 HG51616 Bolt, 5/16-24 x 1” Patch x x
49 HG44130 Washer, .34 x .88 x .06 x x
50 HG44371 Washer, .63 x 1.0 x .05 x x
51 HG44145 Ring, Retaining x x
52 HG52641 Pawl, Brake x x
53 HG52344 Gear, 16T x
HG52341 Gear, 14T Steel x
54 HG52150 Shaft, Motor x x
55 HG51069 Washer, .72 x 1.16 x .04 x x
56 HG51140 Seal, Lip 18 x 32 x 7 x x
57 HG52114 Filter x x
58 HG52257 Filter Guard x x
59 HG50752 Bolt, 1/4-20 x 3/4” x x
60 HG71410 Seal Kit x x
61 HG71436 Kit, Charge Relief x x
62 HG71411 Kit, Charge Pump x x
63 HG51048 Trunnion Swashplate x x
64 HG50551 Thrust Bearing x x
65 HG51462 Thrust Bearing x x
66 HG71579 Kit, Motor Cylinder Block x x
67 HG70723 Kit, Cylinder Block x x
68 HG71448 Plate, Bypass x x
69 HG71436 Kit, Charge Relief x x
70 HG52137 Bolt, Hex Head 3/8-16 x 1-1/2” Patch x x
Ref. Part 48
No. No. Description 36 52
