37
Section 8
36" CUTTER DECK
1 04021-09 Nut, Elastic Stop 3/8-16
2 424615 Bracket, Belt Guide
3 04043-04 Flatwasher, 3/8 - .391 x .938 x .105
4 424367 Dust Shield
5 04112-06 Nut, 3/4-16 Spiral Lock
6 04063-01 Key, 1/4 x 1/4 x 1-1/4”
7 483667 Belt, Cutter Deck
8 483422 Pulley, 5” Idler
9 483324 Pulley, 5.73” OD - 25mm Bore
10 483375 Spring, Idler
11 04001-154 Bolt, Hex Head 5/16-18 x 4-3/4”
12 482245 Spring, Discharge Chute
13 04021-10 Nut, Elastic Stop 5/16-18
14 462031 Discharge Chute Assembly
15 04001-12 Bolt, Hex Head 5/16-18 x 1-3/4”
16 04107-05 Bolt, Hex Head 3/8-16 x 2” Special Lock
17 04110-03 U-Nut, 3/8-16
18 483361 Lever, Deck Level
19 04041-11 Flatwasher, 3/8-.406 x 1.50” x 7 Ga.
20 483453-03 Bearing
21 462133 Idler Arm (incl. item #20)
22 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2”
23 43711 Spacer
24 462135 Cutter Deck w/Decals, SFZ36
25 04021-22 Nut, Elastic Stop 5/16-18
Ref. Part
No. No.
Description
26 04030-03 Lockwasher, 5/16 Spring
27 04021-11 Nut, Elastic Stop 7/16-14
28 04019-04 Nut, Serrated Flange 3/8-16
29 04003-42 Bolt, Carriage 7/16-14 x 2-1/4”
30 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr. 8
31 04001-09 Bolt, Hex Head 5/16-18 x 1”
32 451926 Shaft Weldment
33 04019-03 Nut, Serrated Flange 5/16-18
34 482295 Wheel, Anti-Scalp
35 04001-77 Bolt, Hex Head 3/8-16 x 3-1/2”
36 461950 Spindle Assembly
37 04043-06 Flatwasher, 5/8-.688 x 1.75 x .134 HD
38 04030-07 Lockwasher, 1/2 Spring
39 04001-121 Bolt, Hex Head 5/8-11 x 1-1/2”
40 483304 Debris Shield
41 483303 Bearing
42 43693 Spacer, Bearing
43 462014 Spindle Housing Assembly (incl. 41, 42)
44 43694 Protector, Bearing
45 43695 Shaft, Spindle
46 04001-175 Bolt, Hex Head 5/16-18 x 1-1/2” Gr.8
47 482878 Cutter Blade, 18”
48 43708 Pivot, Idler
49 04041-38 Flatwasher, 3/8-.406 x 2.25” x .1875
Ref. Part
No. No.
Description
