55
Section 8
FUEL AND ELECTRICAL SYSTEM - SFZ48 & SFZ52
** Available through the individual engine manufacturer.
1 48298 Fuse, 20amp
2 483473 Switch
3 483621 Wire Harness, Main
4 483474 Switch, Seat
5 483537 Hourmeter
6 48029-13 Battery Cable, Red 25”
7 48029-11 Battery Cable, Black 27”
8 04001-44 Bolt, Hex Head 1/4-20 x 1/2”
9 04020-02 Nut, 1/4-20
10 483555 Fuel Tube Assy.
11 48059-01 Clamp, Fuel Hose 1/4”ID
12 483617 Fuel Hose , 1/4” ID Non-Perm. (order by inch)
13 ** Fuel Filter
14 483571 Cover, Sealed Double
15 483629 Fuse Holder
16 48029-09 Battery Cable, Red 9”
17 04017-04 Bolt, Hex Head 1/4-20 x 1/2” Serrated Flange
18 461996 Battery Cover (incl. items 19 & 20)
19 483452 Pad, Battery Hold Down
20 483508 Rubber Pad
21 483665 Battery (not avail. through Scag)
22 483381 Muffler, Briggs & Stratton
483383 Muffler, Kawasaki
23 ** Exhaust Gasket
24 ** Lockwasher
25 ** Bolt
Ref. Part
No. No.
Description
Ref. Part
No. No.
Description
26 482547 Cap, Fuel Tank
27 483523 Fuel Gauge Assy.
28 483278 Solenoid
29 04011-13 Bolt, Self Tapping 1/4-20 x 3/4” Shakeproof
30 483364 Tank, LH
31 483434 Throttle Cable (Briggs & Stratton
483645 Throttle Cable (Kawasaki)
32 462036 Instrument Panel w/Decal
33 483435 Choke Cable (Briggs & Stratton)
483646 Choke Cable (Kawasaki)
34 483472 Ignition Switch
35 483366 Key, Ignition
483609 Key with Shroud
462036 Key Assembly w/Fob
36 483162 PTO Switch
37 04001-08 Bolt, Hex Head 5/16-18 x 3/4”
38 04030-03 Lockwasher, 5/16” Spring
39 04040-15 Flatwasher, 5/16-.375 x .875 x .083
40 04001-11 Bolt, Hex Head 5/16-18 x 1-1/2”
41 04107-03 Bolt, Hex Head 3/8-16 x 1-1/4” Special Lock
42 04110-03 U-Nut, 3/8-16
43 462009 Fuel Tank Assy, RH
44 483536 Grommet
45 482571 Bushing, .56” Dia. Viton
46 482588 Clip, Wire
47 483642 Double Fuse Assy. (incl. items 1, 14, 15, 46)
