Scag Power Equipment FREEDOM Z SFZ User Manual
Page 57
53
Section 8
FUEL AND ELECTRICAL SYSTEM - SFZ36
** Available through the individual engine manufacturer.
1
48298
Fuse, 20amp
2
483473
Switch
3
483621
Wire Harness, Main
4
483474
Switch, Seat
5
483537
Hourmeter
6
48029-13
Battery Cable, Red 25”
7
48029-11
Battery Cable, Black 27”
8
04001-44
Bolt, Hex Head 1/4-20 x 1/2”
9
04020-02
Nut, 1/4-20
10
483557
Fuel Tube Assy.
11
48059-01
Clamp, Fuel Hose 1/4”ID
12
483617
Fuel Hose , 1/4” ID Non-Perm. (order by inch)
13
**
Fuel Filter
14
483571
Cover, Sealed Double
15
483629
Fuse Holder
16
48029-09
Battery Cable, Red 9”
17
04017-04
Bolt, Hex Head 1/4-20 x 1/2” Serrated Flange
18
461996
Battery Cover (incl. items 19 & 20)
19
483452
Pad, Battery Hold Down
20
483508
Rubber Pad
21
483665
Battery (not avail. through Scag)
22
483381
Muffler, Briggs & Stratton
483383
Muffler, Kawasaki
23
**
Exhaust Gasket
24
**
Lockwasher
25
**
Bolt
26
482547
Cap, Fuel Tank
27
483523
Fuel Gauge Assy.
28
483278
Solenoid
29
04001-03
Bolt, Hex Head 1/4-20 x .63”
Ref. Part
No. No.
Description
Ref. Part
No. No.
Description
30
483672
Tank, LH
31
483434
Throttle Cable (Briggs & Stratton)
483645
Throttle Cable (Kawasaki)
32
462136
Instrument Panel w/Decal
33
483435
Choke Cable (Briggs & Stratton)
483646
Choke Cable (Kawasaki)
34
483472
Ignition Switch
35
483366
Key, Ignition
483609
Key with Shroud
462069
Key Assembly w/Fob
36
483162
PTO Switch
37
04001-08
Bolt, Hex Head 5/16-18 x 3/4”
38
04030-03
Lockwasher, 5/16” Spring
39
04040-15
Flatwasher, 5/16-.375 x .875 x .083
40
04001-11
Bolt, Hex Head 5/16-18 x 1-1/2”
41
04107-03
Bolt, Hex Head 3/8-16 x 1-1/4” Special Lock
42
04110-03
U-Nut, 3/8-16
43
462099
Fuel Tank Assy, RH
44
483536
Grommet
45
482571
Bushing, .56” Dia. Viton
46
482588
Clip, Wire
47
483642
Double Fuse Assy. (incl. items 1, 14, 15, 46)
48
04010-12
Screw, #10-32 x 3/4”
49
04019-01
Nut, Serrated Flange #10-32
50
424830
Control Cover, LH
51
424822
Control Cover, RH
52
04017-05
Bolt, Hex Head 1/4-20 x 3/4” Serrated Flange
53
04019-02
Nut, Serrated Flange 1/4-20
54
04031-01
Lock Washer, #10 External Tooth
55
04020-01
Nut, Hex #10-32
