97-707 • Bg • reV. 7/06
9
PRESSURE
W
ASHER Specifications
ITeM pART No. deSCRIpTIoN qTY
1 83-005150010 check connector 1
83-005060108 ‡ o-ring 068 3
3 83-00510000 shutter spring 1
4 83-00410000 shutter 1
5 83-004060109 ‡ o-ring 63190 sH 1
6 83-00517010 1/4 g plug 1
7 83-005030101 m8 lock nut 1
8 83-005100100 Knob 1
9 83-005150101 Washer 1
10 83-005400403 4000 psi spring (Black) 1
11 83-005150011 stem guide union 1
1 83-00500010 ‡ Back ring
13 83-005060106 ‡ o-ring 031 1
14 83-00516050 stem al606 1
83-005160514 stem al607 1
15 83-005106301 spring pin 1
16 83-005000101 Back ring
17 83-005060101 ‡ o-ring 050 1
18 83-00500003 Body By pass 1/4 g-F 1
83-0050006 Body By pass 3/8 g-F 1
19 83-00506000 3/8 gasket 1
0 83-00106019 ‡ o-ring 043 1
1 83-00106000 ‡ seat 1
83-001160000 ‡ Ball 1
3 83-005100003 Ball spring 1
4 83-005150009 seat union 1
5 83-00503000 m8 nut
6 83-005170101 3/8g plug
7 83-00506001 gasket 1
83-005650200 ‡ Repair kit
AdJUSTING
start with the valve set at its lowest spring tension.
raise pressure by turning adjusting knob clockwise
until pressure is at the desired position. do not over-
tighten.
open and close spray gun to be sure pressure is correct.
raise or lower pressure by adjusting the knob.
do not by-pass more than 5 minutes when by-passing
to the suction side of the pump.
UNloAdeR exploded vIeW pARTS lIST
