Page 20
97-707 • Bg • reV. 7/06
OPERA
TOR’S MANU
AL
PRESSURE
W
ASHER
0
d SeRIeS pUMp exploded vIeW
ToRqUe
SpeCS
item # Ft.-lbs
14
65
17
5
8
34
9
43
13
ITeM pART No.
deSCRIpTIoN
qTY
1
70-009
crankcase
1
*
see Kits Below plunger oil seal
3
3*
70-060181
o-ring Ø1.78 x 8.30
3
4*
70-10131
pressure ring 15mm
3
5*
see Kits Below "V" seal, 15mm
6
6*
70-030048
support ring 15mm
6
7*
70-030049
intermed. ring 15mm
3
8
70-16010
Brass plug 1/"
1
9
70-060307
copper Washer 1/"
1
10
70-1608
manifold Housing
1
11*
70-060155
o-ring Ø1.78 x 15.54
6
1*
see Kits Below Valve assembly
6
13*
70-0601
o-ring Ø.6 x 18.77
6
14
70-160147
Valve plug
6
15
70-060308
copper Washer 1/4
1
16
70-16011
Brass plug g1/4
1
17
70-180118
manifold stud Bolt
8
18
70-140001
Washer
8
19
70-060306
copper Washer 3/8
1
ITeM pART No.
deSCRIpTIoN
qTY
0
70-160117
Brass plug 3/8
5
70-18011
screw
1
6
70-00318
Bearing cover
7
70-0050
Bearing seal
1
8
70-150003
snap ring
1
9
70-01300
Ball Bearing
30
70-000605
crankshaft
1
31
70-00604
crankshaft Key
1
3
70-16001
oil dipstick
1
33
70-000110
crankshaft seal
1
34*
70-03011
plunger nut
3
35*
70-1003
plunger, 15mm
3
36*
70-14007
copper spacer
3
37*
70-060130
o-ring Ø1.78 x 5.8
3
38*
70-000913
teflon ring
3
39*
70-00030
plunger rod
3
40
70-15004
connecting rod pin
3
41
70-010008
connecting rod
3
4
70-14010
spring Washer
6
d SeRIeS pUMp exploded vIeW pARTS lIST
