HoSe & SpRAY GUN ASSeMBlY pARTS lIST
HoSe & SpRAY GUN ASSeMBlY
ITeM pART No. deSCRIpTIoN qTY
1 4-011031 Wand assy., 35-1/” side grip,
w/couplers, (BX) 1
4-01103 Wand assy., side grip W/1/4”
coupler 35-1/” (Bg) 1
4-0140 spray gun assy. (BX) 1
4-0146 spray gun, ap 1000 (Bg) 1
3 -000 coupler, 1/4” Female, Brass
(Bg) 1
(BX)
4 nozzle, please see exploded Views For sizes
5 4-0093450Bc Hose, 3/8" x 50', 1 Wire Blue,
w/coupler (Bg-5737,
Bg-8037, Bg-303037) 1
4-0073450rc Hose, 3/8" x 50', Wire Blue,
w/coupler (Bg-304037,
Bg-35337, Bg-373537) 1
3
4
1
2
5
6
10
8
9
7
3
ITeM pART No. deSCRIpTIoN qTY
5 4-00750c Hose, 3/8" x 50', Wire
pressure Flex w/coupler
(BX-373539) 1
4-0033450c Hose, 3/8" x 50', 1 Wire tuff
skin, w/coupler (BX-5739,
BX-8039, BX-303039) 1
6 -00 coupler, 3/8” Female, Brass 1
7 3-101 injector, detergent, non-adjust,
3-5 gpm, .083 1
8 -9040 clamp, Hose
9 4-0080000 tube, 1/4” x 1/” clear Vinyl 6 ft.
10 -1904 strainer 1
