PRESSURE
W
ASHER
OPERA
TOR’S MANU
AL
repair Kit
numBer
70-6116 70-6081 70-6084 70-6110 70-60810 70-6085
Kit
description
*plunger
seal
4035
plunger
seal
4030
5030
plunger
seal
3540
**complete
seal packing
4035
complete
seal packing
4030
5030
complete
seal packing
3540
item numBers
included
4, 5, 7 4, 5, 7 4, 5, 7
3, 4, 5,
6, 7, 8
3, 4, 5,
6, 7, 8
3, 4, 5, 6,
7, 8
numBer oF
cYlinders Kit
Will serVice
3 3 3 1 1 1
* For 4035H High Heat packings, use 70-611 **For 4035H High Heat packings, use 70-6113
repair Kit
numBer
70-6117 70-608 70- 6083 70-60007 70-260027
Kit
description
plunger
gm-4035
4035H
plunger
4030
5030
plunger
3540
complete
Valve
plunger oil
seals
item numBers
included 34, 35, 36,
37, 38, 39
34, 35, 36,
37, 38, 39
34, 35, 36,
37, 38, 39
1, 13, 14 3
numBer oF
cYlinders Kit
Will
serVice
1 1 1 6 3
ITeM pART No. deSCRIpTIoN qTY
35* 70-14001 copper spacer 3
36* 70-060103 o-ring Ø1.78 x 7.66 3
37* 70-000904 teflon ring 3
38* Kit 70-05 plunger (4035, 4035H) 3
Kit 70-06 plunger (4030, 5030) 3
39* 70-140015 copper spacer 3
40 70-000301 plunger rod 3
41 70-010001 connecting rod 3
4 70-150001 snap ring 6
43 70-15001 connecting rod pin 3
44 70-14010 spring Washer 6
45 70-180105 connecting rod screw 6
46 70-060009 cover gasket 1
47 70-00350 crankcase cover 1
48 70-06030 gasket, g3/8 1
49 70-160117 Brass plug 3/8 1
50 70-070001 sight glass g3/8 1
51 70-18011 cover screw 5
5 70-00099 ▲ Bach ring 1/" (4035H) 3
*
available in kit (see below) ▲ not shown
M SeRIeS pUMp exploded vIeW pARTS lIST (CoNT.)
