ITeM pART No. deSCRIpTIoN qTY
1 630683 crankcase 1
860361 plunger guide 3
3 ❖ plunger seal 3
4 ◆ pressure ring o-ring 3
5 pressure ring 18 mm 3
6 ◆ V-sleeve 18 mm 6
7 ◆ support ring 18 mm 6
8 intermediate ring 18 mm 3
9 915630 plug 3/8" 3
10 780565 copper Washer 3/8"
11 783854 manifold Housing 1
1 780560 Washer 8
13 875571 manifold stud Bolt 1
14 ★ Valve seat o-ring 6
15 ★ Valve seat 6
16 ★ Valve plate 6
17 ★ Valve spring 6
18 ★ Valve cage 6
19 96657 manifold plug o-ring 6
0 83335 manifold plug 6
1 87557 Hex screw 8
615488 Bearing cover
3 615489 Bearing protector W/o sight glass 1
878575 sight glass 1
818575 o-ring for sight glass 1
4 860141 crankshaft snap ring 1
5 808895 Ball Bearing
6 81410 oil dipstick 1
7 855893 gasket 3/8" 3
8 ✤ plunger nut 3
9 ✤ ceramic plunger sleeve 18 mm 3
30 ✤ copper spacer 3
31 ✤ plunger rod o-ring 3
3 ✤ teflon ring 3
33 89669 plunger rod 3
34 86014 connecting rod pin 3
35 630688 connecting rod assembly 3
36 780564 spring Washer 6
37 878197 allen screw 6
38 735313 crankcase cover allen screw 4
39 6300 crankshaft seal 1
40 8734 crankcase cover 1
41 855889 crankcase cover gasket 1
4 63000 crankshaft 1
C SeRIeS pUMp exploded vIeW pARTS lIST
