49
Section 8
ENGINE AND ATTACHING PARTS
42
1 482931 Engine, Kawasaki 17hp (FH541V-AS36)
483024 Engine, Kawasaki 19hp (FH580V-AS33)
2 482349 Extension, Oil Drain 4”
3 04104-01 Bolt, Torx 3/8-16 x 1”
4 424014 Bumper, Rear
5 04001-19 Bolt, Hex Head 3/8-16 x 1”
6 483102 Muffler, SZC Kawasaki
7 04019-04 Nut, Serr. Flange 3/8-16
8 04011-12 Bolt, 5/16-18 x 3/4” Self Tap
9 424133 Mounting Bracket, Muffler
10 04104-01 Bolt, Torx 3/8-16 x 1”
11 424072 Skidplate
12 04003-12 Bolt, Carriage 5/16-18 x 3/4”
13 04019-04 Nut, Elastic Stop 3/8-16
14 04019-03 Nut, Elastic Stop 5/16-18
15 04003-12 Bolt, Carriage 5/16-18 x 3/4”
Ref. Part
No.
No. Description
