Scag Power Equipment SZC - Manual (Page 49)

45
Section 8
SZC ROLL OVER PROTECTION SYSTEM
1 483140 SZC ROPS
2 483150 Seat Belt, ROPS
3 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
4 04040-13 Flatwasher, 1/2-.562 x 1.375 x .109
5 04021-19 Nut, Center Lock 1/2-13
Ref. Part
No. No.
Description
