Scag Power Equipment SZC - Manual (Page 43)

39
Section 8
1 461833 Cutter Deck (incl. decals) x
461834 Cutter Deck (incl. decals) x
2 04015-14 Bolt, Hex Head 1/4-20 x 3/4” x
04001-172 Bolt, Hex Head 1/4-20 x 1” x
3 04020-09 Nut, 5/8-11 x x
4 48926 Tapered Hub, 1.125” Bore x x
5 483110 Pulley, 4.15 O.D. (36”) x
482646 Pulley, 4.75 O.D. (42”) x
6 04021-09 Nut, Elastic Stop 3/8-16 x
7 04043-04 Flatwasher, 3/8-.391 x .938 x .105 x x
8 482416 Pulley, 5” Idler x x
9 483001 Belt, Cutter Deck (36”) x
483002 Belt, Cutter Deck (42”) x
10 48114-04 Grease Fitting 1/4-28 Self Tapping x x
11 04020-08 Nut, 1/2-20 UNF x x
12 48542 Rod End, 1/2-20 RH Thread x x
13 04021-07 Nut, Elastic Stop 1/2-13 x x
14 04001-87 Bolt, Hex Head 1/2-13 x 4” x x
15 461769 Push Arm Assembly (incl. 10, 11, 12) x x
16 451240 Rod Weldment, Push Arm x x
17 04001-09 Bolt, Hex Head 5/16-18 x 1” x x
18 04019-03 Nut, Serrated Flange 5/16-18 x x
19 45944 Shaft Weldment, Guide Roller x x
20 48038 Roller x x
21 48224 Bearing x x
22 461632 Idler Arm Assembly (incl. item 21) x x
23 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr. 8 x x
24 04019-04 Nut, Serrated Flange 3/8-16 x x
25 04001-54 Bolt, Hex Head 3/8-16 x 3” x x
26 43660 Pivot, Idler x x
27 04110-03 U-Nut, 3/8-16 x x
28 04063-20 Key, 1/4 x 1/4 x 1” x x
29 04001-176 Bolt, 5/16-18 x 1-3/4” Gr. 8 x x
30 43590 Spacer, Spindle x x
31 482959 Cutter Blade, 12.20” x
483014 Cutter Blade, 14-3/4” x
32 04043-06 Flatwasher, 5/8-.688 x .75 x .134 HD x x
33 04001-180 Bolt, Hex Head 5/8-11 x 8-1/2” x
04001-41 Bolt, Hex Head 5/8-11 x 9-1/2” x
34 461776 Spindle Assembly (36”) x
461663 Spindle Assembly x
35 43663 Shaft, Cutter Spindle (36”) x
36A”& 42A" CUTTER DECKS
Ref. Part
No. No.
Description 36 42
Ref. Part
No. No.
Description 36 42
43589 Shaft, Cutter Spindle x
36 481024 Seal, Top x x
37 481022 Bearing Assembly x x
38 48114-04 Grease Fitting x x
39 48677 Relief Fitting, Tapered Spindle x x
40 43644 Spindle Housing x x
41 43312 Spacer, Outside x x
42 43296 Spacer, Inside x x
43 481025 Seal, Bottom x x
44 43297 Spindle Bushing, Bottom x x
45 481035 Nut, Special 1 - 1/16-18 x x
46 04001-23 Bolt, 3/8-16 x 4-1/2” x x
47 04001-77 Bolt, 3/8-16 x 3-1/2” x x
48 04030-03 Lock washer, 5/16” x x
49 04021-22 Nut, Elastic Stop 5/16-18 Gr. 8 x x
50 04001-11 Bolt, 5/16-18 x 1-1/2” x x
04001-12 Bolt, 5/16-18 x 1-3/4” x x
51 04021-10 Nut, Elastic Stop 5/16-18 x x
52 482245 Spring, Discharge Chute x x
53 04001-154 Bolt, Hex Head 5/16-18 x 4-3/4” x x
54 481625-01 Knob w/stud, 3/8-16 x 1-1/4” x x
55 424055 Belt Cover x
56 483112 Spring x x
57 482783 Pulley, 5” Idler x x
58 461295 Discharge Chute x x
