Scag Power Equipment SZC - Manual (Page 4)

II
TABLE OF CONTENTS (CONT'D)
SUBJECT PAGE
Section 6 - Adjustments
6.1 Parking Brake Adjustment .................................................................................................... 22
6.2 Travel Adjustments ............................................................................................................... 23
6.3 Throttle Control and Choke Adjustments .............................................................................. 24
6.4 Belt Adjustment .................................................................................................................... 24
6.5 Belt Alignment ...................................................................................................................... 24
6.6 Cutter Deck Adjustments ..................................................................................................... 25
Section 7 - Maintenance
7.1 Maintenance Chart ............................................................................................................... 28
7.2 Lubrication Fitting Points ...................................................................................................... 29
7.3 Hydraulic System .................................................................................................................. 31
7.4 Engine Oil ............................................................................................................................. 32
7.5 Engine Fuel System .............................................................................................................. 32
7.6 Engine Air Cleaner ................................................................................................................ 33
7.7 Battery .................................................................................................................................. 33
7.8 Drive Belts ............................................................................................................................ 35
7.9 Cutter Blades ........................................................................................................................ 35
7.10 Tires ...................................................................................................................................... 36
7.11 Body, Deck and Upholstery .................................................................................................. 36
Section 8 - Replacement Parts
Notes .............................................................................................................................................. 37
SZWC36A, 42A Cutter Deck .................................................................................................. 38-39
Cutter Deck Controls ................................................................................................................ 40-41
Sheet Metal Components .......................................................................................................... 42-43
SZC Roll Over Protection System ............................................................................................ 44-45
Drive System Components ....................................................................................................... 46-47
Engine and Attaching Parts - Kohler ....................................................................................... 48-49
Steering Components ................................................................................................................ 50-51
Brake Components ................................................................................................................... 52-53
Fuel and Hydraulic System ....................................................................................................... 54-55
Electrical System ...................................................................................................................... 56-57
Hydraulic Pump (BDP-10A) .................................................................................................... 48-59
Replacement Decals ................................................................................................................. 60-61
Electrical Schematic (Kohler & Kawasaki) ................................................................................... 62
Warranty Statement ............................................................................................. Inside Back Cover
