Sharp AR-C160 - Manual (Page 134)

7-16
CHAPTER
7
Loading copy paper
1 Press the paper tray control button on the large capacity
tray.
● The button lamp will blink while the feed table is lowering and
will go out when the tray is ready to be opened.
2 When the button lamp goes out, pull the paper tray out.
● Do not pull the paper tray out before the button lamp goes out.
3 Fan the copy paper.
4 Load the paper onto the feed table.
● Be sure to load paper appropriate for the large capacity tray.
See page 7-15.
● Do not exceed the maximum height line.
5 Gently push the large capacity tray back into place.
● The paper tray control button lamp will blink as the feed table
returns to the feed position and will light up steadily when it is in
position to feed.
The large capacity tray will automatically lower when the tray runs out
of paper.
OPTIONAL EQUIPMENT
Large capacity tray (AR-LC2N)
LARGE CAPACITY TRAY (AR-LC2N)
Maximum height line
