5-9

CHAPTER

5

MISFEED REMOVAL

COPIER TROUBLE?

Misfeed removal

Misfeed in the optional duplex module

NOTES:

●

For misfeed removal from an optional staple sorter (AR-SS2) or an
optional finisher (AR-FN4), please refer to chapter 7 Optional
Equipment.

●

If any other misfeed locations are indicated, be sure to remove any
misfed paper from these locations before pulling out the duplex
module. If not, a sheet of paper in another location may become torn
and difficult to remove.

1

Open the left side cover.

2

Remove the misfed paper.

3

Close the left side cover

4

Pull out the duplex module.

MISFEED HAS OCCURRED.

CLEAR INDICATED AREA.

PRESS FOR RECOVERY INSTRUCTIONS.
