MR0012J 9710 System Assurance Guide 4-9
PDU Power Cables
■
PDU Power Cables
The PDU power cables are included when you order the PDU feature code.
They are listed below in case you still want to order them separately.
■
Serial Cables, 9710 to Host
If the robot is controlled by a serial RS423 connection, the 9710-end of the
cables requires a female DB9 connector.
Table 4-1. PDU Cables
Description Part Number Quantity
❑
Cable assembly, international, 200–240 V, 10 A, 3 m
(10 ft), 2-wire and ground.
For main PDU 411063801 ________
❑
Cable assembly, international, 200–240 V, 10 A, 2.4 m
(8 ft), harmonized cord 1.5 mm
2 , EuroPlug.
For optional PDU
10083241 ________
❑
Cable assembly, South Korea, 100–127 V, VCTF cord
3 x 1.25 mm
2 , KSC 8305 plug.
For optional PDU
10083657 ________
❑
Cable assembly, domestic, twisted lock, 200–240 V,
20 A, 2.5 m (8.2 ft), 14 AWG SJT cord.
For main PDU 10083638 ________
❑
Cable assembly, domestic, twisted lock 200–240 V,
15 A, 2.5 m (8.2 ft), 16 AWG SJT cord.
For optional PDU 10083639 ________
❑ Cable assembly, domestic, 100–127 V, 20 A, 3 m
(10 ft), 14 AWG SJT cord, NEMA 5-20P (IEC 320 plug).
For main PDU 310287201 ________
❑
Cable assembly, domestic, 100–127 V, 15 A, 2 m (7 ft),
16 AWG SJT cord, NEMA 5-15P (IEC 320 plug).
For optional PDU 10083242 ________
❑
Cable assembly, domestic, twisted lock, 100–127 V,
20 A, 2.5 m (8.2 ft), 14 AWG SJT cord.
For main PDU 10083641 ________
❑
Cable assembly, domestic, twisted lock, 100–127 V,
15 A, 2.5 m (8.2 ft), 16 AWG SJT cord.
For optional PDU 10083642 ________
