Hardware Order Worksheets
4-4 9710 System Assurance Guide MR0012J
DLT Drives
Figure 4-2 on page 4-5 lists the DLT8000 model and feature number. Figure 4-3
on page 4-6 and Figure 4-4 on page 4-7 list the DLT7000 and DLT4000 feature
numbers. The drives will ship with either a SCSI Fast/Narrow Differential
interface or a SCSI Fast/Narrow Single-Ended interface. You will need SCSI Fast/
Wide 68-pin connectors to connect to the differential drives.
Note: The DLT8000 is only available with a differential interface.
Each kit contains one DLT drive, differential terminator, slides, drive mounting
tray, drive actuator mechanism, drive chassis, DLT power supply, cooling,
hardware to mount the drive to the tray, and the drive power cord.
Note: If more than six drives are ordered, the customer must order the PDU.
The PDU feature code includes the PDU, the appropriate power cord,
the PRM card, and an additional drive-to-LSM interface cable.
