40
OthersOthers
Dimensions
D-Sub Pin Assignments
PC 15-Pin mini D-Sub
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Signal to be connected
Red
Green
Blue
GND
GND
Red GND
Green GND
Blue GND
No Connection
Digital GND
GND
SDA
Horizontal Sync
Vertical Sync
SCL
ON/OFF
INPUT SELECT
AUTO SYNC
POWER
STATUS
230 mm/9
9
⁄ 16
˝
177 mm/6 15 ⁄
16
˝
27 mm/ 1
1
⁄ 16
˝
61 mm/2 13 ⁄
32
˝
48 mm/
1 7 ⁄
8
˝
11 mm/
7 ⁄
16
˝
231 mm/9
15
⁄ 16
˝
