Page 38

H8QG6/i+-F Serverboard User's Manual
2-12
JIBTN1 Header (only on H8QG6+-F)
A RAIDKey header, located at JIBTN1,
provides RAID function support in order to
use RAID 5 SAS support.
LAN1/2 (Ethernet Ports)
Two Gigabit Ethernet ports (designated
LAN1 and LAN2) are located beside the
VGA port. Additionally, there is a dedicated
LAN port for IPMI on top of the two rear USB
ports. These Ethernet ports accept RJ45
type cables.
LAN Ports (LAN1/2)
Pin Defi nition
Pin# Defi nition Pin# Defi nition
1
P2V5SB
10
SGND
2
TD0+
11
Act LED
3
TD0-
12
P3V3SB
4
TD1+
13
Link 100 LED
(Yellow, +3V3SB)
5
TD1-
14
Link 1000 LED
(Yellow, +3V3SB)
6
TD2+
15
Ground
7
TD2-
16
Ground
8
TD3+
17
Ground
9
TD3-
18
Ground
Note: NC indicates no connection.
Universal Serial Bus Ports
Two Universal Serial Bus ports (USB 2.0) are
located beside the Keyboard and Mouse PS2
ports. One additional Type A port (USB6) is
also included on the motherboard. See the
table on the right for pin defi nitions.
Universal Serial Bus Ports
Pin Defi nitions (USB 0/1,
USB6)
USB0/1
Pin # Defi nition
USB6
Pin # Defi nition
1
+5V
1
+5V
2
PO-
2
PO-
3
PO+
3
PO+
4
Ground
4
Ground
USB Headers
Four USB 2.0 headers (USB2/3 and USB4/5)
are also included on the motherboard.
These may be connected to provide front
side access. A USB cable (not included) is
needed for the connection. See the table on
the right for pin defi nitions.
Universal Serial Bus Headers
Pin Defi nitions
(USB2/3, USB4/5)
JUSB2, JUSB3
Pin # Defi nition
Pin # Defi nition
1
+5V
2
+5V
3
PO-
4
PO-
5
PO+
6
PO+
7
Ground
8
Ground
9
Key
10
NC
Note: NC indicates no connection.
