14 Installing the Interactive Whiteboard 99-00668-00 REV B0
4. Connect the MOD8 cable to the controller.
5. Connect the DB9 end of the SMART USB adapter cable to the controller. You’ll connect the
other end of this cable to your computer when you complete the installation.
OR
If you ordered a straight-through DB9-to-DB9 serial cable with your interactive whiteboard,
connect one end to the controller. You’ll connect the other end of this cable to a serial port on
your computer when you complete the installation.
NOTE: You can order a straight-through DB9-to-DB9 serial cable from SMART Technologies.
To do this, contact SMART Technical Support (page 27).
OR
If you ordered the WC2 Wireless Serial Adapter (Part No. WC2-NA) with your interactive
whiteboard, connect one radio to the controller. To do this, follow the instructions that came
with your kit. You’ll connect the second radio to the computer later.
To complete the installation, see below.
MOD8 Cable Controller
DB9 Connector
