99-00668-00 REV B0 Installing the Interactive Whiteboard 9
7. With the assistance of another person, carefully place the overlay over the flat-panel display,
and then maneuver the corner brackets until they fit around the flat-panel display’s corners.
There will be a slight gap on each side.
8. Tighten the thumbscrews to hold the overlay against the flat-panel display.
9. Attach a bracket with a triangular notch to the bottom-right corner (when you’re looking at the
front of the overlay) by reaching behind the overlay and slipping the bracket over the threaded
posts on the overlay. Insert thumbscrews over each post.
CAUTION Take care when mounting and then positioning the overlay. The overlay can be
scratched if it’s held tight to the flat-panel display and then moved in any
direction.
