ASSEMBLY
STEP3: Fasten protective cover on the upright
1) Attach the crossbar (84) between the left and right upright then secure using
4 x M8x20mm Bolts () and 4 x M8 washers ().
2) Tighten all bolts and fasteners now
X4
X4
Console crossbar
Tighten all bolts and fasteners now
