9-7
9.1.4 Considerations for Using
(1) Do not back feed paper after cutting paper using the autocutter unit because it will cause a paper
jam.
(2) To prevent paper from jamming, feed paper or print feed 7 mm or more after cutting paper.
(3) To make the most efficient use of paper, as shown in Figure 9-7, print area A for the next print
portion after printing area B, and then cut the paper.
Print start position.
Cut position
PRINT AREA A
PRINT AREA B
PRINT AREA A
PRINT AREA B
Execute a paper cutting after printing
and the next
.
PRINT AREA B
PRINT AREA A
‘ The distance between the print position and cut position when mounting the autocutter onto the printer is
approximately 13 mm.
‘ Do not perform a consecutive print across print area A and print area B.
Figure 9-7 Using the Paper Effectively When Cutting
Print start position
Cut position
PRINT AREA A
PRINT AREA B
PRINT AREA A
PRINT
One-time
printing
area
Paper feed direction
