Automatic fanfold feeding 27
The following table provides a general guide for setting the adjustment lever.
Experiment with different settings until you find the one that gives you the print
quality you want.
Continuous use of the wrong adjustment lever setting can drastically reduce
print head life!
Automatic fanfold feeding
❏
See “Loading paper” on page 8 for details on using fanfold paper.
Manual sheet feeding
You can use the following procedure to manually feed cut-sheets of paper into
the printer.
❏
Make sure that there is no fanfold paper in the printer. If there is, use the
procedure under “Parking fanfold paper” on page 12 to park the fanfold
paper and prepare for manual sheet feeding.
Paper Type Weight Per Sheet Thickness
Recommended
Position
Single-sheet
14 lbs (52 gsm) 0.06 mm 1
17 lbs (64 gsm) 0.08 mm 1
21 lbs (81 gsm) 0.10 mm 1
28 lbs (104 gsm) 0.13 mm 1
42 lbs (156 gsm) 0.19 mm 2
Copy
2-ply 11 lbs (40 gsm) 0.13 mm 2
3-ply 11 lbs (40 gsm) 0.20 mm 3
4-ply 11 lbs (40 gsm) 0.26 mm 4
5-ply 11 lbs (40 gsm) 0.33 mm 5
6-ply 11 lbs (40 gsm) 0.39 mm 6
7-ply 11 lbs (40 gsm) 0.45 mm 7
