– 20 –
6. GENERAL SPECIFICATIONS
Printing method Serial impact dot matrix printing,
9 wires
Number of print columns 29 columns (10CPI), 44 columns (15CPI)
Print speed
Approx. 2 lines/sec
Print direction Bi-directional
Line spacing 1/6 inch
Paper feed method Friction Feed
Paper feed speed Approx. 12 lines/sec
Character set ASCII 96 characters
Special 64 characters
Block graphics* 64 characters
Katakana (Japanese) 64 characters
Font configuration 10CPI Ordinary characters 5
×
9 dots
Block graphics* 6
×
6 dots
15CPI Ordinary characters 7
×
9 half dots
Block graphics* 5
×
6 dots
* Graphic Feed Not Available
Character size
10CPI 2.00 (H)
×
2.42 (V) mm
15CPI 1.32 (H)
×
2.42 (V) mm
Character spacing 10CPI 2.55 mm (1/10 inch)
15CPI 1.70 mm (1/15 inch)
Dot spacing 10CPI H=0.425 mm V=0.353 mm
15CPI H=0.340 mm V=0.353 mm
Gross dot 10CPI 174 dots/wire/line
15CPI 220 dots/wire/line
Print area 10CPI 73.53 mm
15CPI 74.46 mm
Print Buffer Approx. 1.5 KB
Interface Parallel Interface (Centronics compatible)
Peripheral drive 2 outputs (each 1A max. at 12V. Both cannot
operate at the same time.)
External dimensions
(Printer) 202(W)
×
200(D)
×
98(H) mm
(without paper holder, DC Power Connector)
(Power supply unit) 60(W)
×
120(D)
×
36(H) mm (without AC cable)
Weight
(Printer) Approx. 1.9 kg
(Power supply unit) Approx. 0.4 kg (without AC cable)
