Star Micronics DP8340RC User Manual

Page 21

– 17 –

CODE

FS
(1C)

FUNCTION

Trigger peripheral unit drive 1 (immediate)

OUTLINE

Causes a peripheral drive 1 pulse to be generated immediately

CODE

SUB
(1A)

FUNCTION

Trigger peripheral unit drive 2 (immediate)

OUTLINE

This command causes a peripheral unit drive 2 pulse to be
generated.
Pulse Duration : 200ms (fixed)
Delay

: 200ms (fixed)

REMARKS

It is impossible to drive peripheral devices 1 and 2 at the
same time.

CODE

CAN
(18)

FUNCTION

Clears print buffer

OUTLINE

Upon input of this code the data buffer and line buffer are
cleared.

CODE

ESC P
(1B)

(50)

FUNCTION

Select 10 CPI

OUTLINE

This code causes the printer to print at 10 CPI. The number
of columns per is 29.

CODE

ESC M
(1B)

(4D)

FUNCTION

Select 15 CPI

OUTLINE

This code causes the printer to print at 15 CPI. The number
of columns per line is 44. When the power is turned on, the
15 CPI mode is selected.
