PROBLEM
POSSIBLE CAUSE
REASON/SOLUTION
Charger will not turn on
when properly connected.
AC outlet is dead.
Poor electrical connection.
Check for open fuse or
circuit breaker supplying AC
outlet.
Check power cord and
extension cord for loose
fitting plug.
The battery is connected
and the charger is on, but is
not charging.
Clips are not making a good
connection.
Check for poor connection
at battery and frame. Make
sure connecting points are
clean. Rock clips back and
forth for a better connection.
The measured current is
much lower than what was
selected.
The charger reached the
maximum voltage and is
reducing the current.
No problem, this is a normal
condition.
BEFORE RETURNING FOR REPAIRS
16.
When a charging problem arises, make certain that the battery is capable
16.1
of accepting a normal charge. Double check all connections, AC outlet for
the correct voltage, charger clips for correct polarity and the quality of the
connections from the cables to the clips and from the clips to the battery
system. The clips must be clean.
When a battery is very cold, partially charged or sulfated, it will not draw
16.2
the full rated amperes from the charger. It is both dangerous and damaging
to a battery to force higher amperage into it than it can effectively use in
recharging.
When an UNKNOWN OPERATING PROBLEM arises, please read the
16.3
complete manual and call the customer service number for information that will
usually eliminate the need for return.
SPECIFICATIONS
17.
Data Plate
120V, 50/60Hz
Model
SI-82-6MA
SI-70MA
SI-1275A
Single Phase Power Supply (Vac)
120
120
120
Frequency (Hz)
50/60
50/60
50/60
Charging Voltage(s) (V)
12
12/24
4
12
Starting Voltage(s) (V)
--
--
12
Effective Charging Current, Continuous (A)
2/6
1
10
2/12
1
Starting Current at 1.0 Volt (minimum) /
Cell (A)
5
--
--
75
5
Max. Power Absorbed Charge/Start (KW)
0.143
.23/.43
.28/1.6
Dimensions (mm)
220 x 170 x
105
270 x 210 x
130
270 x 210 x
130
Weight (Kg)
3.8
6.5
7.5
Circuit Breaker Protected Output
Yes
2
Yes
2
Yes
3
Circuit Breaker Rating (A)
12
20
35
