Determine which post of the battery is grounded (connected) to the chassis.

6.4

If the negative post is grounded to the chassis (as in most vehicles), see step

6.5. If the positive post is grounded to the chassis, see step 6.6.
For a negative-grounded vehicle, connect the POSITIVE (RED) clip from the

6.5

battery charger to the POSITIVE (POS, P, +) ungrounded post of the battery.

Connect the NEGATIVE (BLACK) clip to the vehicle chassis or engine block

away from the battery. Do not connect the clip to the carburetor, fuel lines or

sheet-metal body parts. Connect to a heavy gauge metal part of the frame or

engine block.
For a positive-grounded vehicle, connect the NEGATIVE (BLACK) clip from the

6.6

battery charger to the NEGATIVE (NEG, N, -) ungrounded post of the battery.

Connect the POSITIVE (RED) clip to the vehicle chassis or engine block away

from the battery. Do not connect the clip to the carburetor, fuel lines or sheet-

metal body parts. Connect to a heavy gauge metal part of the frame or engine

block.
Connect charger AC supply cord to electrical outlet.

6.7

When disconnecting the charger, turn all switches to off, disconnect the AC

6.8

cord, remove the clip from the vehicle chassis and then remove the clip from

the battery terminal.
See CALCULATING CHARGE TIME for length of charge information.

6.9

FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE VEHICLE

A SPARK NEAR THE BATTERY

MAY CAUSE A BATTERY

EXPLOSION. TO REDUCE THE

RISK OF A SPARK NEAR THE

BATTERY:

Check the polarity of the battery posts. The POSITIVE (POS, P, +) battery post

7.1

usually has a larger diameter than the NEGATIVE (NEG, N, -) post.
Attach at least a 24-inch (61 cm) long 6-gauge (AWG) insulated battery cable

7.2

to the NEGATIVE (NEG, N, -) battery post.
Connect the POSITIVE (RED) charger clip to the POSITIVE (POS, P, +) post

7.3

of the battery.
Position yourself and the free end of the cable you previously attached to the

7.4

NEGATIVE (NEG, N, -) battery post as far away from the battery as possible –

then connect the NEGATIVE (BLACK) charger clip to the free end of the cable.
Do not face the battery when making the final connection.

7.5

Connect charger AC supply cord to electrical outlet.

7.6

When disconnecting the charger, always do so in the reverse order of the

7.7

connecting procedure and break the first connection while as far away from the

battery as practical.
A marine (boat) battery must be removed and charged on shore. To charge it

7.8

onboard requires equipment specially designed for marine use.
