9.1.7 Fibre Channel Process Login Accept
Table 12 lists Cheetah 15K.5 FC process login accept payload data.
9.1.8 Fibre Channel fabric login
Table 13 lists the fabric login payload from the drive.
Table 12: Process Login Accept (ACC) payload
Bytes
0-15 02 10 00 14 08 00 21 00 00 00 00 00 00 00 00 00
16-31 00 00 00 12
Table 13: Fabric Login (FLOGI) payload
Bytes
0-15 04 00 00 00 09 09 00 00 08 00 08 40 00 00 00 00 Common
16-31 00 00 02 F4 2P 00 CC CC CC UI UI UI 02 00 CC CC
32-35 CC UI UI UI
36-47 00 00 00 00 00 00 00 00 00 00 00 00 Class 1
48-51 00 00 00 00
52-63 00 00 00 00 00 00 00 00 00 00 00 00 Class 2
64-67 00 00 00 00
68-79 80 00 00 00 00 00 08 40 00 00 00 00 Class 3
80-83 00 00 00 00
84-95 00 00 00 00 00 00 00 00 00 00 00 00 Reserved
96-99 00 00 00 00
100-111 00 00 00 00 00 00 00 00 00 00 00 00 Vendor -
112-115 00 00 00 00 Version
CC Bytes (22, 23 and 24) and (30, 31 and 32) are currently factory set to 00 04 CF respectively (subject to change).
UI Unique identifier. This 24-bit field is uniquely assigned to the drive. This same UI appears in the Port Name and
Node Name fields.
P Port identifier field.
1 FLOGI originated on Port A.
2 FLOGI originated on Port B.
