Cheetah 15K.5 FC Product Manual, Rev. D 37
6.5 Mechanical specifications
The following nominal dimensions are exclusive of the decorative front panel accessory. However, dimensions
of the front panel are shown in figure below. Refer to Figure 12 for detailed mounting configuration dimensions.
See Section 8.4, “Drive mounting.”
Figure 12. Mounting configuration dimensions
Height (max): 1.028 in 26.11 mm
Width (max): 4.010 in 101.85 mm
Depth (max): 5.787 in 146.99 mm
Weight (max): 1.85 pounds 0.839 kilograms
S
-Z- T //
J H
L
B
K
[1]
F
[1]
D
E
-Z-
Mounting holes are 6-32 UNC 2B, three
on each side and four on the bottom.
Max screw penetration into side of drive
is 0.15 in. (3.81 mm). Max screw
tightening torque is 6.0 in-lb (3.32 nm)
with minimum full thread engagement of
0.12 in. (3.05 mm).
Notes:
[1]
Inches
A
B
C
D
E
F
H
J
K
L
M
N
P
R
S
T
U
26.10
147.00
101.60
95.25
3.18
44.45
28.50
101.60
6.35
41.60
4.60
1.02
41.28
41.10
7.00
0.38
0.38
1.028
5.787
4.000
3.750
0.125
1.750
1.122
4.000
0.250
1.638
0.181
.040
1.625
1.618
0.276
.015
.015
max
max
± .010
± .010
± .010
± .010
± .020
± .010
± .010
± .010
± .020
± .040
max
max
max
max
± .25
± .25
± .25
± .25
± .50
± .25
± .25
± .25
± .50
± 1.02
max
max
Dimension Table
Millimeters
R REF
A
M
-Z-
-X- N
P
-X- U
C
-X-
REF
