4
Overview
System Components
The XC-EU50/EU50CE Video Camera Module
system comprises the following components.
Connection Diagram
Video camera module
XC-EU50/EU50CE
Camera cables
CCXC-12P02N(2 m)
CCXC-12P05N(5 m)
CCXC-12P10N(10 m)
CCXC-12P25N(25 m)
Camera adaptor
DC-700/700CE
Tripod adaptor
VCT-333I
(Insulated type)
C-mount lens
VCL-50Y-M Close-up ring kit
LO-77ERK
Close-up ring kit
LO-77ERK
XC-EU50/EU50CE
Tripod adaptor
VCT-333I
Camera cables
CCXC-12P02N
CCXC-12P05N
CCXC-12P10N
CCXC-12P25N
Camera adaptor
DC-700/700CE
(Conforms to new EIAJ and
uses 12-pin assignment)
AC
VIDEO OUT
HD/VD
WEN
TRIG
C-mount lens
VCL-50Y-M
