3'' RETURN HEADER
WITH 1 1 /
2
'' STUBS
(3 MODULE)
* 3'' BUILDING
PIPING
(BY OTHERS)
1 1 /
2
'' X 34'' SQUARE NIPPLE
1 1 /
2
'' X 30'' NIPPLE
CAST END CAP
WITH 3 / 4 '' TAPPING.
SUPPLY OR RETURN.
FOR USE WITH LWCO.
3'' SUPPLY HEADER
WITH 1 1 /
2
'' STUBS
(3 MODULE)
1 1 /
2
'' X 4'' NIPPLE
3
1 1 /
2
'' ELBOW
1 1 /
2
'' X 15'' NIPPLE
CAST END CAP
3'' RETURN HEADER
WITH 1 1 /
2
'' STUBS
(2 MODULE)
3'' FLEX JOINTS
(SEE DETAIL "A")
1 1 / 2 '' X 8'' SQUARE NIPPLE
1 1 /
2
'' FLEX JOINT
(SEE DETAIL "A")
1 1 /
2
'' X 4'' NIPPLE
C
FACTORY SUPPLY AND RETURN HEADER ASSEMBLY — OIL
