Samsung Color Dual Quad Network Observation System SSC21WEB User Manual
Page 41
Eng-41
PLAY
STOP
LIVE MODE change
ADMIN MODE change
- SINGLE SCREEN DISPLAY
In case users want to see the camera image at full mode,
Select a target camera by turning camera select key.
After that it’ selected camera image will be displayed at full screen.
*
AT SINGLE DISPLAY
- QUAD MODE DISPLAY
User can switch SINGLE DISPLAY and SEQUENTIAL DISPLAY MODE or QUAD
DISPLAY MODE or QUAD A (QUAD B) TO QUAD B (QUAD A) Press the
Sequence KEY
•
AT QUAD MODE DISPLAY
QUAD A : QUAD DISPLAY MODE From Camera1 to Camera4
QUAD B : QUAD DISPLAY MODE From Camera5 to Camera8
Original Size
Large Size
