Earphone
Accessories
6 5
1.
Power Input Jack (Refer to page 8)
2.
ESP/Album button
(Refer to pages 16, 17)
3.
STOP button ( )
4.
+10 button (Refer to page 16) 5.
Play/Pause button ( ) 6.
SBS / Last Memory button
(Refer to page 15)
9.
10.
11. Volume
12. Earphone Connection jack
(Refer to page 8)
Line Out output jack
(Refer to page 8)
13.
Program button
(Refer to pages 18, 19)
HOLD switch
Bottom of the Main Unit
Buttons and Controls
Main Unit
8.
Skip/Search buttons ( )
(Refer to page 13)
Open switch
7.
Mode button (Refer to page 14)
10 11 12
1
4 5 6 7
9 13
3
2
8
