SMSC USB2507 - Manual (Page 22)

Integrated USB 2.0 Compatible 7-Port Hub
Datasheet
Revision 2.3 (08-27-07) 22 SMSC USB2507
DATASHEET
5.2.3.6 EEPROM Offset 8(h) - Non-Removable Device
5.2.3.7 EEPROM Offset 9(h) - Port Disable For Self Powered Operation
5.2.3.8 EEPROM Offset A(h) - Port Disable For Bus Powered Operation
BIT
NUMBER BIT NAME DESCRIPTION
7:0 NR_DEVICE Non-Removable Device: Indicates which port(s) include non-removable devic-
es. ‘0’ = port is removable, ‘1’ = port is non-removable.
Bit 7= 1; Port 7 non-removable.
Bit 6= 1; Port 6 non-removable.
Bit 5= 1; Port 5 non removable.
Bit 4= 1; Port 4 non-removable.
Bit 3= 1; Port 3 non-removable.
Bit 2= 1; Port 2 non-removable.
Bit 1= 1; Port 1 non removable.
Bit 0 is Reserved, always = ‘0’.
BIT
NUMBER BIT NAME DESCRIPTION
7:0 PORT_DIS_SP Port Disable Self-Powered: Disables 1 or more contiguous ports. ‘0’ = port
is available, ‘1’ = port is disabled.
Bit 7= 1; Port 7 is disabled.
Bit 6= 1; Port 6 is disabled.
Bit 5= 1; Port 5 is disabled.
Bit 4= 1; Port 4 is disabled.
Bit 3= 1; Port 3 is disabled.
Bit 2= 1; Port 2 is disabled.
Bit 1= 1; Port 1 is disabled.
Bit 0 is Reserved, always = ‘0’
BIT
NUMBER BIT NAME DESCRIPTION
7:0 PORT_DIS_BP Port Disable Bus-Powered: Disables 1 or more contiguous ports. ‘0’ = port
is available, ‘1’ = port is disabled.
Bit 7= 1; Port 7 is disabled.
Bit 6= 1; Port 6 is disabled.
Bit 5= 1; Port 5 is disabled.
Bit 4= 1; Port 4 is disabled.
Bit 3= 1; Port 3 is disabled.
Bit 2= 1; Port 2 is disabled.
Bit 1= 1; Port 1 is disabled.
Bit 0 is Reserved, always = ‘0’
